Position vertically or horizontally thanks to the elegant aluminium wall-bracket. Resistant to dust, moisture and UV, the AM-1 is far tougher than it looks.
Performance that endures
AM-1 is entirely sealed, in order to keep the elements at bay. It’s tough and hard-wearing too, and its clever one-piece mounting system with 220-degree rotation means it’s ready to perform wherever you want it to, come rain or shine.
Easy to install, great to listen to
A one-plug, simple-to-install mounting system means AM-1 is happy vertically or horizontally. Plus, smart engineering means AM-1 sounds great whichever way you choose to mount it.
Specified and built without compromise
With our trademark Nautilus tube-loaded 25mm aluminium dome tweeter and 130mm glassfibre mid/bass driver supplemented by an auxiliary bass radiator for solid, powerful bass response, AM-1 has sound and scale way beyond its compact dimensions.
Specifications:
- Technical features: Nautilus™ tube loaded aluminum dome tweeter, Glassfiber cone bass/midrange, Auxiliary Bass Radiator (ABR)
- Drive units: 1x ø25mm (1in) aluminum dome high-frequency, 1x ø130mm (5in) glassfiber cone bass/midrange
- Frequency response: 51Hz - 22kHz on reference axis (wall mounted)
- Harmonic distortion: <1% 200Hz - 20kHz (86dB, 1m)
- Recommended amplifier power: 20W - 100W into 8Ω on unclipped program
- Description: 2-way system with Auxiliary Bass Radiator (ABR)
- Frequency range: -6dB at 46Hz and 50kHz (wall mounted)
- Sensitivity: 86dB (2.83V, 1m)
- Nominal impedance: 8Ω (5.2 Ω min)
- Height: 310mm (12 1/4in)
- Width: 180mm (7in)
- Depth: 210mm (8 1/4in)
- Net weight: 4kg (8.8lb)
